VG54-NA Vehicle Gateway

Clear
Quantity:
Buy Now

The Samsara VG54-NA Vehicle Gateway

The Samsara VG54-NA Vehicle Gateway is an advanced sensor platform for fleets. The Samsara VG54-NA Vehicle Gateway provides live GPS tracking and analytics, sensor data, FMSCA-approved ELD capabilities, engine diagnostics, built-in Wifi hotspot with companies like At&t, driver workflows, and more. The Samsara VG34 Vehicle Gateway is a part of a complete solution designed to enhance efficiency, safety, customer service, and compliance.

  • Advanced GPS with real-time fleet visibility
  • Works with other Samsara products seamlessly (dash cams, sensors, etc)
  • Includes 4G LTE WiFi hotspot
  • Compatible with several types of vehicles: light, medium, and heavy-duty

With this gateway, you can receive (1) customized reports and logs, (2) easy-to-use management tools, (3) AI-based analytics. These analytics allow you to manage your fleets and enable drivers to more productive. The Vehicle Gateway is perfectly suited for refrigerated vehicle fleets, providing wireless temperature monitoring. It also caters to specialized fleets, offering insights into power takeoff, lift arm, plows, sweepers, fluid tanks, gas pressure, and various other aspects.

If you want a demo of this product, you can contact us here.

Warranty

All Samsara hardware has a warranty that lasts as long as a valid license for said hardware is maintained. For more information, click here.

Product Specifications

Where The Gateway Works

  • Seamlessly adapts to a diverse range of vehicles
    • Passenger cars, light trucks, tractor trailers, heavy-duty industrial vehicles, and specialized vehicles
  • Tested for moisture, extreme temperatures, vibration, and shock

Material

  • Polycarbonate

Encasing Dimensions

  • 71mm x 118mm x 23 mm

Weight

  • 173 g

USB Port

  • 4 USB 2.0 Ports

Input Power

  • 12V and 24V vehicles via diagnostic port connection or direct wiring harness.

AUX Line Port

  • 8 Pin Molex Connector

Diagnostic Port

  • 16 Pin Molex Connector

Power Consumption

  • High Power: Approx. 2W
  • Moderate Power: Approx. 0.8W
  • Low Power: Approx. 0.2W

Supported AUX Lines

  • 5 Digital Inputs
  • 1 Digital Output

Temperature Range

  • -40° to 85°C

CAN/bus Diagnostics Interface

  • High Speed CAN, J1939, J1708, RP-1226
  • Single Wire CAN, Secondary High Speed CAN

Location Tracking

  • Advanced positioning system reads from GPS and GLONASS and other global navigation satellite systems
  • GNSS (Global Navigation Satellite System) Supported – GPS L1, Glonass L1, & Galileo
  • Supports external GNSS antenna (only HW-VG54-NAE)
  • Supports GNSS Jamming Detection

Wireless Sensors

  • Compatible with EM-series wireless temperature monitors, Driver ID tokens, and IM-series industrial input modules.

Connect to the Cloud

  • See real-time location visibility, dispatch, reporting and alerts

Easy Driver App

  • Less distracted drivers and ELD-ready logging made easy

Backup Battery

  • activates and sends tamper detection alerts instantly if power is interrupted

Third Party Camera Integration

  • Yes

Cellular Data and WiFi

  • 4G LTE cellular connectivity, 3G fallback where LTE is unavailble. LTE –> quad band 2/4/5/12/13;
  • Integrated WiFi hotspot (802.11g/n, 2.4Ghz) provides high-speed WiFi data to WiFi-compatible devices.

Operating Area

  • United States, Canada, Mexico

Data Security

  • All internet connectivity secured via SSL with 256-bit AES encryption (military-grade)
